The structural glass railing has an extruded aluminum shoe that is encased with cladding that can be either stainless steel or aluminum. Top caps or rails are available in round and U-channel forms in materials and finishes that match the cladding as well as the assist rail. Wood is a popular option.

• Cladding can be stainless steel or coated aluminum.
• Top rails, caps and assist rails are available in stainless steel, aluminum and wood, in a variety of different shapes and profiles.
• Glass can be monolithic or laminated, clear or tinted in a variety of shades, ½" to ¾" thick.

If you would like to see how our Structural Glass Railing system would work with your project, contact us



Projects Incorporating Structural Glass Railing Railings

Trine University - College of Health Professions

Railing
Structural Glass Railing
Infill
Glass
Finish
Aluminum cladding and top cap powder coated anodized silver with wood assist and 1/2" clear tempered glass

Duke Realty Headquarters

Railing
Structural Glass Railing, Smoke Baffles, KLEAR™, QUAD™
Infill
Glass
Finish
Stainless Steel QUAD™/KLEAR™ Railing Combination with U-Channel Top Cap, Clear Tempered Glass Infill Panels and Grab Rail
